YJ-1313-3X Small CNC 3 axis water jet cutting machine
Model No: YJ-1313-3X
Product Name: Small CNC 3 axis water jet cutting machine
Processing material: Ceramic tile, aluminum plate, stone, marble, granite, metal, glass, stainless steel, wood, steel plate, copper, rubber, plastic, artificial stone, quartz stone and other materials.
Origin: Foshan, Guangdong, China
Brand name: YONGTAO
Mode of transport: Sea, railway (container transport)
Mechanical construction: cantilever construction.
Brief Introduction of water jet machine:
Yongtao CNC 3 axis water jet cutting machine, it is a small water jet cutting machine, using pure water mixed abrasive waterjet cutting. Through high pressure water jet to the plate, realize the material to cut off the way. The water jet machine covers an area of small, cost-effective, specially for the small pieces of plate cutting.
The cutting head is vertical, processing speed fast, compared with 5 axis water jet cutting machine, 3 axis of water jet tile cutting machine twice as fast than 5 axis water jet efficiency. It using computer CAD drawing software, windows system, can effectively realize the graphical output command and cutting. You can make any graphics plane cutting, cutting on a variety of materials. Since high precision lead screw using, it can achieve higher machining precision, the operator only need understand the CAD drawing and then operate the machine. the water jet cutter have the advantage on simple operation, convenient maintenance, good stability.Yongtao machinery produce waterjet cutting machine, has more than 10 years of manufacturing experience, all countries around the world have used customer ceramic water jet cnc machine, loved by the masses of customers.
The characteristics of 3 axis water jet cnc machine:
1, vertical cutting, fast processing speed.
2, cantilever structure design, easy to enter the plate, unload the plate.
3. Select components of international brands to facilitate the replacement of parts by users from various countries.
4. Adopt stainless steel protective cover, dustproof, waterproof, rust-proof and corrosion-proof, easy to clean with water, keep water cutting platform shining as new all year round.
5. Servo drive, high precision screw, linear guide rail, can achieve no clearance movement, ensure the smooth movement of the machine, no vibration.
6. unique sand valve design, simple structure, flow sand more smooth, can work for a long time without blocking sand, more convenient maintenance.
7.Humanized design, excellent workmanship, international standard quality, the preferred brand of large enterprises.
Sizes of full set of small waterjet machine :
No.
|
Packing size of water jet cutting machine
|
1
|
YJ-1313-3X water jet cutting table:2.65m*2.3m*1.6m
|
2
|
Supercharger system:1.3m*0.95m*1.25m
|
3
|
Abrasive system:0.6m*0.6m*0.95m
|
4
|
CNC control system:0.65m*0.65m*1.67m
|
5
|
Water cooling system: 1.0m*1.0m*1.6m
|
All component of 3 axis small water jet cutter:
No.
|
Full set of 3 axis water jet cutting machine
|
1
|
Water jet cutting table 1set
|
2
|
CNC control system 1set
|
3
|
Abrasive system 1set
|
4
|
Supercharger system 1set
|
5
|
Water cooling system 1set
|
Main parameter of 3 axis water jet :
Max cutting thickness for metal:40mm
|
Glass, stone, tile, marble, granite thickness:50mm
|
Max cutting size:1300mm*1300mm
|
Cutting precision:±0.1mm
|
Dia. of gem:0.33mm
|
Dia. of water jet nozzle:1.0mm
|
Flew rate:3.7L/min
|
Max consumption of sand:190g/min
|
Oil:#46/#68(Great Wall hydraulic oil)
|
Voltage:220V/380V/415V、50/60HZ
|
Drawing tools: Auto CAD
|
Operation system:Windows XP
|
Z-axis strip:130mm
|
Max. Water pressure:420Mpa
|
Working pressure:300-380Mpa
|
Main motor power:30kw
|
Total power:37kw
|
Cutting head:3 axis water jet
|
