YSKP-1200 3+4 Stone Groove Cutting And Polishing Machine

Description of YSKP-1200 3+4 Stone Groove Cutting And Polishing Machine
YSKP-1200 3+4 stone groove cutting and polishing machine is the latest product of Yongtao machinery, the granite cutting and polishing machine is specially designed by client’s requirement for stone grooving and polishing. The machine can process marble, artificial stone, granite etc materials. There are 3 heads in the front: the first head make bevel cutting, the second head make vertically cutting, and the third head make horizontally cutting.The direction of slab put is that the smooth surface will be downward. The cut off material will automatically falling down by gravity. And then the remaining material will be grooved and polished. The polishing parts adopt air pressure structure, which can ensure the material stable transmission. Due to this, the machine need a air compressor to assist. The machine can do grooving and polishing in one time.The polished product are brightness, don’t need to make waxing. It is very popular in stone groove processing factory.

Technical Parameter of YSKP-1200 3+4 Stone Groove Cutting And Polishing Machine

Conveyor motor	2.2kw
Cutting head motor	5.5kw*3pcs
Numbers of cutting head	3头
Diameter of blade	Φ250*60
Numbers of polishing head	4pcs
Diameter of polishing head	Φ150*30
Polishing head motor	3kw*4
Conveyor belt width	350mm
Maxi processing width	1000mm
Processing speed	1-3m
Processing thickness	30-60mm
Size of machine	4.5*1.9*1.7m
Total power	30.70kw
Weight	2000kg
