YTQZ-A/2-1200 Two Blade CNC Tile Cutting Machine

This double-blade CNC porcelain tile cutting machine is independently developed and manufactured by Yongtao Machinery, designed to deliver high-precision and high-efficiency cutting for modern ceramic tile factories. The machine adopts a dual-blade cutting structure, where the front blade performs a half-depth cut and the rear blade completes the final cut, ensuring smooth cutting edges and excellent dimensional accuracy.

Equipped with a full digital CNC control system, the machine provides precise and stable cutting performance. The cutting depth can be adjusted manually, while the cutting width and processing dimensions are controlled digitally through the CNC positioning system. This combination allows flexible operation with reliable accuracy for different tile sizes and production requirements.

The machine supports a maximum cutting size of 1200 × 1200 mm and can cut tiles into two pieces of 1200 × 600 mm with consistent size on both sides and no deviation. With a belt-driven transmission system, it offers fast processing speed, capable of cutting 2 to 4 meters of tile per minute, significantly improving production efficiency.

Using 130–150 mm diameter cutting blades, the machine achieves low cutting cost while maintaining high cutting precision and stable performance. Its optimized mechanical structure ensures smooth operation, reduced vibration, and long service life. In addition, the machine features a modern and robust appearance design, combining functionality with a professional industrial look.

With high accuracy, fast cutting speed, and reliable CNC control, this double-blade CNC porcelain tile cutting machine is an ideal solution for tile manufacturers seeking efficient, precise, and cost-effective tile cutting equipment.
